installation method:

1. Trim one end of the prepared drip irrigation pipe (or PE pipe) evenly.

2. Insert the double barb end of the pipe fitting into the trimmed drip irrigation pipe (or PE pipe) to ensure that all

double barbs are submerged in the drip irrigation pipe (or PE pipe).

Precautions

1. The insertion depth of the drip irrigation pipe or PE pipe must exceed the barb depth of the pipe fitting.

2. During construction in winter, because PE pipes are hard and difficult to connect, they can be connected

after soaking in warm water.
